Ultrasonic Probe 1 MHz for GS200/GS200i/FlowDop200

Produkt Informationen

Article No. VK-10151

Ultrasonic Probe 1 MHz for GS200/GS200i/FlowDop200

Single-element transducer with a frequency of 1 MHz suitable for investigations with large penetration depths, equipped with special plug for connection to GS200, GS200i or FlowDop200

mehr Informationen

Lieferzeit:

prices visible to registered users only

Back to list

Request a Quote

Product name
Subject*
Request*
E-Mail*
Last name
First Last
Anschrift
Street Address Address Line 2 City State / Province / Region ZIP / Postal Code Country
*
- I accept the privacy policy.
CAPTCHA

Add to wishlist

Description

The blue-marked ultrasonic probes are characterised by high sound intensity and short sound impulses. These are especially suitable for the pulse-echo method. The probes have a robust metal housing and are moulded so that they are watertight at the sound surface. The probes are delivered with the special plug for connection to the GS200 / GS200i. Due to their high sound intensity they are especially suitable for investigations with large penetration depths, of highly attenuating materials and for the generation of Rayleigh and/or shear waves. They can here be used as transmitters or receivers.

Technical Data

Frequency: 1 MHz
Dimensions: length = 70 mm, diameter = 27 mm
Cable length: approx. 1 m
Sound adaptation to water/acrylic
Special plug with probe identification for connection to GS200 / GS200i

Experiments

PHY01	Basics of pulse echo method (A-Scan)
PHY02	Sound velocity in solids
PHY03	Acoustic attenuation in solids
PHY06	Frequency dependence of resolution power
PHY07	Shear waves in solids
PHY08	Ultrasonic B-Scan
PHY16	Mechanical scan methods
PHY20	Determination of focus zone
PHY22	Phase shift and resonance effects
PHY23	Dispersion of ultrasonic waves (Lamb waves)
IND02	Detection of cracks with Rayleigh waves
MED02	Ultrasonic imaging at breast phantom (mammasonography)
